Reflex gauge glass, also called reflex sight glass, reflex level gauge glass, boiler glass and reflex level gauge. It is installed in a variety of towers, tanks, tanks, boxes and other containers for direct indication of the level of the medium in the equipment glass.The material of reflex sight glass is usually borosilicate glass and aluminosilicate glass. Reflex gauge glass divided into single and multiple grooves. You can buy reflex gauge glass with one, two, three, or four groove. They are available in Type A, Type B, and Type H series and measure up to 400mm in length. The dimensions vary from series to series, but they all comply with DIN 7081.
Our reflex gauge glasses can resist temperatures of up to 245°C when exposed to steam water and 400˚C in less aggressive environments. They boast high mechanical strength and can survive pressure applications of up to 400 bar without affecting the accuracy of readings. But note that you can’t use Mica protection for the reflex glass of a gauge. That means corrosion can occur if you expose the measuring instrument to media with high pH values, such as acids and alkaline solutions.
Another important feature is transparency. Our quality control processes ensure the surface of reflex gauge glasses is free from blisters, streaks, inclusions, and other defects that may make readings harder to get.
Product Features
- excellent visibility enhanced by grooves
- Customize form and dimension.
- No strip, bubble, scrap or crack
Size
| Type A | ||||||
| No | L | B | S | Roman No | Size | Part No |
| 0 | 95 | 30 | 17 | – | 95X30X17 | OVRA00 |
| 1 | 115 | 30 | 17 | I | 115X30X17 | OVRA01 |
| 2 | 140 | 30 | 17 | II | 140X30X17 | OVRA02 |
| 3 | 165 | 30 | 17 | III | 165X30X17 | OVRA03 |
| 4 | 190 | 30 | 17 | IV | 190X30X17 | OVRA04 |
| 5 | 220 | 30 | 17 | V | 220X30X17 | OVRA05 |
| 6 | 250 | 30 | 17 | VI | 250X30X17 | OVRA06 |
| 7 | 280 | 30 | 17 | VII | 280X30X17 | OVRA07 |
| 8 | 320 | 30 | 17 | VIII | 320X30X17 | OVRA08 |
| 9 | 340 | 30 | 17 | IX | 340X30X17 | OVRA09 |
| 10 | 370 | 30 | 17 | X | 370X30X17 | OVRA10 |
| 11 | 400 | 30 | 17 | XI | 400X30X17 | OVRA11 |
| Type B | ||||||
| No | L | B | S | Roman No | Size | Part No |
| 0 | 95 | 34 | 17 | – | 95X34X17 | OVRB00 |
| 1 | 115 | 34 | 17 | I | 115X34X17 | OVRB01 |
| 2 | 140 | 34 | 17 | II | 140X34X17 | OVRB02 |
| 3 | 165 | 34 | 17 | III | 165X34X17 | OVRB03 |
| 4 | 190 | 34 | 17 | IV | 190X34X17 | OVRB04 |
| 5 | 220 | 34 | 17 | V | 220X34X17 | OVRB05 |
| 6 | 250 | 34 | 17 | VI | 250X34X17 | OVRB06 |
| 7 | 280 | 34 | 17 | VII | 280X34X17 | OVRB07 |
| 8 | 320 | 34 | 17 | VIII | 320X34X17 | OVRB08 |
| 9 | 340 | 34 | 17 | IX | 340X34X17 | OVRB09 |
| 10 | 370 | 34 | 17 | X | 370X34X17 | OVRB10 |
| 11 | 400 | 34 | 17 | XI | 400X34X17 | OVRB11 |
| Type H | ||||||
| No | L | B | S | Roman No | Size | Part No |
| 0 | 95 | 34 | 22 | – | 95X34X22 | OVRH00 |
| 1 | 115 | 34 | 22 | I | 115X34X22 | OVRH01 |
| 2 | 140 | 34 | 22 | II | 140X34X22 | OVRH02 |
| 3 | 165 | 34 | 22 | III | 165X34X22 | OVRH03 |
| 4 | 190 | 34 | 22 | IV | 190X34X22 | OVRH04 |
| 5 | 220 | 34 | 22 | V | 220X34X22 | OVRH05 |
| 6 | 250 | 34 | 22 | VI | 250X34X22 | OVRH06 |
| 7 | 280 | 34 | 22 | VII | 280X34X22 | OVRH07 |
| 8 | 320 | 34 | 22 | VIII | 320X34X22 | OVRH08 |
| 9 | 340 | 34 | 22 | IX | 340X34X22 | OVRH09 |
| 10 | 370 | 34 | 22 | X | 370X34X22 | OVRH10 |
| 11 | 400 | 34 | 22 | XI | 400X34X22 | OVRH11 |
Safe individual packaging
It’s our responsibility as a gauge glass manufacturer to deliver every piece to you safely. That’s why we use individual packaging to protect the products from defects en route. Gauge glasses are then placed into cardboard boxes (for small orders). And if you find any damaged pieces after unpacking, we’ll replace them with new ones at no charge.
If you order gauge glasses in bulk, you can opt for wooden packaging instead of cardboard boxes for extra protection (no fumigation is included). We can also add any markings or logos to the glass pieces and packaging of your choice.
OVICTOR Gauge Glass are currently used in industrial facilities in the USA, the UK, Europe, and Asia. Our pieces are synonymous with superior quality, but there’s another way we can prove it to you. Request a free reflective glass gauge sample by leaving your inquiry!
