Sight Glass with Light

/
Sight Glass with Light

Sight Glass with Light

Type: sight glass

Product Item:OV-SG-L

Grade: Industrial

Material: Carbon steel/Stainless steel

Connection: welding

Sight glass with light allows you to quickly control the vision of the process in progress. lighting devices further improve the visibility of the process media.

We provide lighting components such as halogen lamps or energy-saving LED lights. LED light source has more advantages. In addition to significantly longer service life and lower power consumption, LED lights also have the advantage of low calorific value. This “cold-light property” prevents burning on the glass.

Product Features

  • Has light source for a clearer view and ease of operation
  • Effective in most operating environments
  • Easy to install and maintain
  • Longer service life

Specification of Sight Glass with Light

Operating Pressure

0.2–1 MPa

Operating Temperature

-20 °C to +250 °C
Chamber Material

Carbon steel; Stainless steel 304 or 316, Titaniumor alternative

Gauge Glass Material

Borosilicate glass, Quartz glass
Sealing Gaskets

NBR gasket; Graphite composite gasket; PTFE gasket

Way of Observation

Visual inspection
Way of Connection

Welding

Notes: Other specifications available upon request.
