Full view sight glass is also called inline sight glass, tubular sight glass, cylinder type sight glass, straight sight glass and pipeline sight glass. Full view sight glass is an 360 degree view flow indicator which is suitable for low pressure applications, moderate flow rates and where maximum visibility is required. The full view sight glass is available with different glass lengths. Its main component is a glass tube of design length, which will stand the max working temperature, pressure. with both ends fixed by carbon steel or stainless steel. The connection method can be flange connection, welding connection, threaded connection and quick clamp connection.This type of sight flow indicators is not available in mechanical strain situation.
Full view sight glass is one of the normal accessories on industrial pipeline installations. It can observe the flow reaction of liquid, gas, steam, and other media in the pipeline at any time. It can also monitor the production to avoid accidents during the production process. It is often used in petroleum, chemical, chemical fiber, pharmaceutical, and other production pipelines.
Product Features
- 360° panoramic observation
- Convenient operation
- Good sealing performance
- High working efficiency
- Alkali resistance and acid resistance
| Specification of Full View Sight Glass | |
| Drift diameter | 1″- 4″, |
| Glass tube material | Borosilicate glass tube, Quartz Glass tube |
| Glass tube wall thickness | According to max pressure of application |
| Glass tube Length | According to client’s request |
| Material | Stainless Steel 304, 316L, |
| Sealing Gasket | NBR, EPDM, SILICON, VITON,PTFE, FPM |
| Surface treatment | 180~420Grit or unpolished |
| Connection mode | Welded, Clamped, Threaded, Flanged |
| Standard | ISO, DIN, IDF, SMS |
| Application | Pharmacy, beer, food, dairy, beverage, cosmetic, chemical industry |
| OEM and Customized | According to the order quantity,Negotiable |
